INTRAlux Ultimate

Featuring the latest fibre innovation, for 3X faster moisture absorption from the first step, Ultimate is our go-to barrier matting option for clients wanting premium performance and sustainability

  • 5 year Warranty
  • Medium Strength Rating

INTRAlux Ultimate Features

  • Innovative polyamide fibre enables rapid moisture absorption even if users don’t wipe their feet
  • 900g/m² pile weight enables rapid moisture evaporation
  • Market-leading environmental credentials
  • Available with PureBase, our PVC-free backing
  • 100% Econyl regenerated nylon yarn
  • Available in a range of 9 nature-inspired colours
  • Excellent Bfl-s1 fire resistance
  • Suitable for heavy commercial applications (class 33)
  • Available as an insert within aluminium systems

INTRAlux Ultimate

  • 901 Ruby

  • 904 Sandstone

  • 905 Truffle

  • 906 Night Sky

  • 907 Anthracite

  • 910 Stone

  • 912 Lichen

  • 913 Forest

  • 914 Teracotta

Product ReferenceINTRAlux Ultimate, Polyamide Sheet Barrier Matting
Material900g/m² pile weight recycled polyamide fibre with PVC or PureBase backing
InstallationWith surface of mat level with adjoining floor coverings Surface mounted with low profile ramped edging trim
LocationZones 2+3
ConstructionEconyl recycled polyamide yarn (100%) and either vinyl or PVC-free PureBase backing
Weight3.7kg/m2
Depth8.5mm
Fire RatingBfl-s1
Roll Size20m x 2m
Sustainability100% Econyl fibre, phthalate free or PVC-free backing (Elite, Ultimate & Select)
A2.5mm
B6mm
1PVC or PureBase Backing
2Fibre pile
3Subfloor
INTRAlux profile diagram

PRODUCT DOWNLOADS

Product Brochure

Download

CAD Cross-Section

BIM IFC

BIM RFA

O&M Manual

Download
