Aluminium modular tile system for creative entrance design. Available with a full range of rubber and fibre inserts for internal and external applications.
INTRAform DM Modular
Typical Application
High Traffic locations such as Shopping Centres, Transport Hubs, Commercial Offices, retail stores etc
INTRAform DM Modular Features
- Unique aluminium Entrance Matting in a box off the shelf for next day service.
- Tile format for ease of installation
- Tiles can be easily replaced in the event of damage
- Full range of rubber and fibre inserts available for internal and external applications.
INTRAlux Elite
INTRAlux Linear
INTRAlux Select
Zone 1 inserts
INTRAlux Ultimate
INTRAlux Elite
INTRAlux Linear
INTRAlux Select
Zone 1 inserts
INTRAlux Ultimate
INTRAlux Elite
INTRAlux Linear
INTRAlux Select
Zone 1 inserts
INTRAlux Ultimate
| Product Reference | INTRAform DM Modular Entrance Matting |
| Strength Rating | High – suitable for areas with heavy foot and wheeled traffic |
| Zonal Location | Use Zone 1 inserts for external areas Use Zone 2 inserts for internal areas Combination Zone 1 & 2 inserts can be specified for dual performance Surface mounted applications with use of ramped edging |
| Construction | 100% recycled aluminium construction. Closed construction Interlocking Plank system. |
| Typical Application | High Traffic locations such as Shopping Centres, Commercial Offices, retail stores etc |
| Design Options | Wide range of design options available Bespoke anodised to special order |
| Weight | 11.2kg/m2 |
| Matwell Framing | INT019 |
| Slip Rating | Will vary with insert, in excess of PTV 38 |
| Warranty | 10 years |
| Sustainability | 100% recycled aluminum. All inserts recyclable/re-usable 100% Econyl Fibre (Elite, Ultimate & Select) |
Profile
| A | 19mm |
| B | 17mm |
| C | 66.4mm Module |
| D | 132.8mm Plank size |
| 1 | Finished Floor surface |
| 2 | Recessed matwell frame |
| 3 | Levelling latex to matwell base |
| 4 | Screed sub-floor |
| 5 | Screw fixings |
