INTRAlink² recycled PVC

A high performance, 100% recycled PVC modular tile with outstanding eco-credentials and moisture absorbing properties. Suitable for multi-directional traffic, it’s quick to install with a wide range of insert colours and design options available.

Typical Application

High traffic locations such as retail, shopping centre, sports, education and leisure facilities

  • 5 Year Warranty
  • EPD Available
  • Closed Construction
  • High Strength Rating

INTRAlink² recycled PVC Features

  • 100% recycled PVC with 100% Econyl inserts
  • Excellent moisture absorbency and brushing action
  • Robust, closed construction, modular tile system
  • Suitable for heavy, multi-directional traffic
  • Cost-effective solution that’s quick and easy to install
  • Designed and manufactured in the UK
  • Wide range of insert colours, features and design options
  • Ideal for retail, education, healthcare, sports and leisure

INTRAlux Elite

  • 601 Red

  • 602 Blue

  • 604 Coco

  • 605 Brown

  • 606 Grey

  • 607 Anthracite

  • 608 Black

  • 609 Purple

  • 610 Turquoise

INTRAlux Ultimate

  • 901 Ruby

  • 904 Sandstone

  • 905 Truffle

  • 906 Night Sky

  • 907 Anthacite

  • 910 Stone

  • 912 Lichen

  • 913 Forest Green

  • 914 Terracotta

INTRAlux Select

  • 207 Grey

  • 208 Black

Product ReferenceINTRAlink² Heavy duty recycled PVC grid Entrance Matting
Strength RatingHigh – suitable for areas with heavy foot and wheeled traffic
Zonal LocationZone 2 inserts for internal areas
ConstructionClosed construction, interlocking tile format – Tile size 250mm x 250mm. UV resistant, hardwearing 100% recycled PVC – with 100% Econyl recycled polyamide fibre inserts. PVC-free (PureBase) backing option available with Ultimate inserts
Typical ApplicationHigh traffic locations such as retail, shopping centre, sports, education and leisure facilities
Design OptionsLogos and multiple bespoke shapes, pattern and colour arrangements can be created with the tile inserts
Weight10.7kg/m²
Matwell FramingINT014 (Recessed) or INT012 (Ramped) Framing
Slip RatingWill vary with insert, in excess of PTV 38
Warranty5 years
Sustainability100% recycled PVC carrier 100% Econyl Fibre inserts PVC-free PureBase option available with Ultimate inserts All inserts recyclable
PackagingPackaged in cases of 24 tiles (1.5m2) for ease of delivery and handling
A14mm
B12mm
C112mm Insert
D250mm Module
1Finished Floor surface
2Recessed matwell frame
3Levelling latex to matwell base
4Screed sub-floor
5Screw fixings
