Excellent for all areas with restricted matwell recesses or surface mounted applications – offering all the benefits of a heavy duty matting system, in performance, appearance and longevity.
INTRAform Low Profile
Typical Application
High Traffic locations such as Shopping Centres, Transport Hubs, Supermarkets, Commercial Offices etc
.
INTRAform Low Profile Features
- Heavy Duty 12mm Aluminium matting system
- Suitable for surface mounted applications
- Compatible with all inserts
- Closed construction – simple to clean and maintain
- Exceptionally hardwearing and durable
- Fully DDA compliant and suitable for wheelchair access
- Fully recycled aluminium construction
INTRAlux Elite
INTRAlux Linear
INTRAlux Select
Zone 1 inserts
INTRAlux Ultimate
INTRAlux Elite
INTRAlux Linear
INTRAlux Select
Zone 1 inserts
INTRAlux Ultimate
INTRAlux Elite
INTRAlux Linear
INTRAlux Select
Zone 1 inserts
INTRAlux Ultimate
| Product Reference | INTRAform Low Profile Entrance Matting |
| Strength Rating | Extreme – suitable for areas with heavy foot and wheeled traffic |
| Zonal Location | Use Zone 1 inserts for external areas Use Zone 2 inserts for internal areas Combination Zone 1 & 2 inserts can be specified for dual performance |
| Construction | 100% recycled aluminium construction. Closed construction Interlocking Plank system. |
| Typical Application | High Traffic locations such as Shopping Centres, Commercial Offices etc |
| Design Options | Bespoke anodised to special order |
| Weight | 11.3kg/m2 |
| Matwell Framing | INT014 & INTR012 |
| Slip Rating | Will vary with insert, in excess of PTV 38 |
| Warranty | 10 years |
| Sustainability | 100% recycled aluminum. All inserts recyclable/re-usable 100% Econyl Fibre (Elite, Ultimate & Select) |
| EPD Carbon data A1-A3 (production stage) | 57.7 Kg CO2 eq/m2 |
Profile
| A | 14mm |
| B | 11mm |
| C | 33mm Profile |
| D | 132.8mm Plank size |
| 1 | Finished Floor surface |
| 2 | Recessed matwell frame |
| 3 | Levelling latex to matwell base |
| 4 | Screed sub-floor |
| 5 | Screw fixings |
