INTRAflow Plus

Ultra heavy duty recessed aluminium entrance matting with extra wide inserts for maximum moisture absorption. Debris channels for maximum dirt retention and moisture dispersion.

Typical Application

High Traffic locations such as Public Buildings, Commercial Offices, travel termini etc

  • 15 Year Warranty
  • EPD Available
  • Closed or Open Construction
  • Extreme Strength Rating

INTRAflow Plus Features

  • Available in open and closed construction
  • Can be used with Waterlogic system
  • Toughest aluminium profiles for highest durability
  • Plank system compatible with INTRAform products
  • Bespoke manufactured sizes with rapid turnaround
  • Easy to install
  • Small sections can be easily replaced in the event of damage
  • Full range of rubber and fibre inserts available for internal and external applications
  • Section 12 compliant FR insert available for specialist applications such as London Underground

Zone 1 inserts

  • Multi directional Rubber

  • Ribbed Rubber

INTRAlux Elite

  • 608 Black

  • 607 Anthracite

  • 606 Grey

  • 609 Purple

  • 602 Blue

  • 610 Turquoise

  • 605 Brown

  • 604 Coco

  • 601 Red

INTRAlux Ultimate

  • 906 Night Sky

  • 907 Anthracite

  • 910 Stone

  • 912 Lichen

  • 913 Forest Green

  • 905 Truffle

  • 904 Sandstone

  • 914 Terracotta

  • 901 Ruby

INTRAlux Select

  • 208 Black

  • 207 Grey

INTRAlux Linear

  • 443 Anthracite

  • 451 Grey

Zone 1 inserts

  • Multi directional Rubber

  • Ribbed Rubber

INTRAlux Elite

  • 607 Anthracite

  • 606 Grey

  • 609 Purple

  • 602 Blue

  • 610 Turquoise

  • 605 Brown

  • 604 Coco

  • 601 Red

INTRAlux Ultimate

  • 906 Night Sky

  • 907 Anthracite

  • 910 Stone

  • 912 Lichen

  • 913 Forest Green

  • 905 Truffle

  • 904 Sandstone

  • 914 Terracotta

  • 901 Ruby

INTRAlux Select

  • 208 Black

  • 207 Grey

Zone 1 inserts

  • Multi directional Rubber

  • Ribbed Rubber

INTRAlux Elite

  • 608 Black

  • 607 Anthracite

  • 606 Grey

  • 609 Purple

  • 602 Blue

  • 610 Turquoise

  • 605 Brown

  • 604 Coco

  • 601 Red

INTRAlux Ultimate

  • 906 Night Sky

  • 907 Anthracite

  • 910 Stone

  • 912 Lichen

  • 913 Forest Green

  • 905 Truffle

  • 904 Sandstone

  • 914 Terracotta

  • 901 Ruby

INTRAlux Select

  • 207 Grey

  • 208 Black

Product ReferenceINTRAflow Plus Entrance Matting
Strength RatingExtreme – suitable for areas with heavy foot and wheeled traffic
Zonal LocationUse Zone 1 inserts for external areas Use Zone 2 inserts for internal areas Combination Zone 1 & 2 inserts can be specified for dual performance Surface mounted applications with use of ramped edging
Construction100% recycled aluminium construction Open drainable/closed construction Interlocking Plank system Fibre and rubber inserts
Typical ApplicationHigh Traffic locations such as Public Buildings, Commercial Offices, travel termini etc
Design OptionsWide range of design options available Bespoke anodised to special order
Weight14.3kg/m2
Matwell FramingINT019
Slip RatingWill vary with insert, in excess of PTV 38
Warranty15 years
Sustainability100% recycled aluminum. All inserts recyclable/re-usable 100% Econyl Fibre (Elite, Ultimate & Select)
A19mm
B16.5mm
C66.4mm Module
D132.8mm  Plank
1Finished Floor surface
2Recessed matwell frame
3Levelling latex to matwell base
4Screed sub-floor
5Screw fixings

PRODUCT DOWNLOADS

Product Brochure

Download

CAD cross-section

BIM IFC

BIM RFA

EPD

O&M Manual

Download
