INTRAform DM

Heavy-duty aluminium entrance matting with extra-wide fibre inserts for optimum moisture absorption in high traffic areas.

Typical Application

High Traffic locations such as Shopping Centres, Commercial Offices, retail stores etc

  • 10 Year Warranty
  • EPD Available
  • Closed Construction
  • Extreme Strength Rating

INTRAform DM Features

  • Heavy-duty aluminium plank system
  • Optimum moisture absorption from extra width fibre inserts
  • Interlocking sections for ease of installation and seamless design.
  • Compatible with standard INTRAform system
  • Fully DDA compliant and produced from 100% recycled aluminium
  • Suitable for all fibre insert ranges, providing exceptional durability and performance

INTRAlux Elite

  • 601 Red

  • 602 Blue

  • 604 Coco

  • 605 Brown

  • 606 Grey

  • 607 Anthracite

  • 608 Black

  • 609 Purple

  • 601 Turquoise

INTRAlux Linear

  • 443 Anthracite

  • 451 Grey

INTRAlux Select

  • 208 Black

  • 207 Grey

Zone 1 inserts

  • Ribbed Rubber

  • Multi Directional Rubber

INTRAlux Ultimate

  • 901 Ruby

  • 904 Sandstone

  • 905 Truffle

  • 906 Night Sky

  • 907 Anthracite

  • 910 Stone

  • 912 Lichen

  • 913 Forest Green

  • 914 Terracotta

INTRAlux Elite

  • 601 Red

  • 602 Blue

  • 604 Coco

  • 605 Brown

  • 606 Grey

  • 607 Anthracite

  • 608 Black

  • 609 Purple

  • 610 Turquoise

INTRAlux Linear

  • 443 Anthracite

  • 451 Grey

INTRAlux Select

  • 208 Black

  • 207 Grey

Zone 1 inserts

  • Ribbed Rubber

  • Multi Directional Rubber

INTRAlux Ultimate

  • 901 Ruby

  • 904 Sandstone

  • 905 Truffle

  • 906 Night Sky

  • 907 Anthracite

  • 910 Stone

  • 912 Lichen

  • 913 Forest Green

  • 914 Teracotta

INTRAlux Elite

  • 601 Red

  • 602 Blue

  • 604 Coco

  • 605 Brown

  • 606 Grey

  • 607 Anthracite

  • 608 Black

  • 609 Purple

  • 610 Turquoise

INTRAlux Linear

  • 443 Anthracite

  • 451 Grey

INTRAlux Select

  • 208 Black

  • 207 Grey

Zone 1 inserts

  • Ribbed Rubber

  • Multi Directional Rubber

INTRAlux Ultimate

  • 901 Ruby

  • 905 Truffle

  • 906 Night Sky

  • 907 Anthracite

  • 910 Stone

  • 912 Lichen

  • 913 Forest Green

  • 914 Terracotta

Product ReferenceINTRAform DM Entrance Matting
Strength RatingExtreme – suitable for areas with heavy foot and wheeled traffic
Zonal LocationUse Zone 1 inserts for external areas Use Zone 2 inserts for internal areas Combination Zone 1 & 2 inserts can be specified for dual performance
Construction100% recycled aluminium construction. Closed construction interlocking plank system.
Typical ApplicationHigh Traffic locations such as Shopping Centres, Commercial Offices, retail stores etc
Design OptionsWide range of design options available Bespoke anodised to special order
Weight12.2kg/m2
Matwell FramingINT019
Slip RatingWill vary with insert, in excess of PTV 38
Warranty10 years
Sustainability100% recycled aluminium. All inserts recyclable/re-usable 100% Econyl Fibre (Elite, Ultimate & Select)
A19mm
B16.5mm
C66.4mm  Module
D132.8mm  Plank size
1Finished Floor surface
2Recessed matwell frame
3Levelling latex to matwell base
4Screed sub-floor
5Screw fixings
